Thread milling cutters

BASS provides various possibilities to produce internal threads with solid carbide thread milling cutters. We will be pleased to develop the solution for your individual application. The catalog program includes thread milling cutters for all thread types in the following models:

GFA

Solid carbide thread milling cutters for a single thread size, suitable for thread depths of up to 2xd

Your advantage: a cost-effective tool for all materials

GFS

Solid carbide thread milling cutters with countersink for a thread depth up to 2xd

Your advantage: high productivity through countersinking and thread milling without tool change

GFM

Solid carbide thread milling cutters for different thread sizes with the same pitch

Your advantage: applicable for threads with the same pitch in a large range of dimensions

BGF

Solid carbide thread milling cutters with 45° countersink for a thread depth of up to 2xd

Your advantage: highest productivity through drilling, countersinking and thread milling without tool change

GFD

The thread milling cutter with three rings of teeth and made of solid carbide, for thread depths up to 3xD and dimension starting at M1.2

Your advantage: process-reliable thread milling in small dimensions

GFE

The thread milling cutter with one ring of teeth and made of solid carbide, for thread depths up to 3xD and dimension starting at M1

Your advantage: process-reliable thread milling in small dimensions

ZBGF

Solid carbide thread milling cutter for core hole drilling and thread milling of one thread size, for thread depth 2×D

Your advantage: high productivity - drilling and thread milling without tool change

Downloads

threading tools and tap holders for the die and mold making industry

Download: DE
Download: EN
Download: FR
Download: IT

threading tools for materials that are difficult to machine

Download: DE
Download: EN
Download: FR
Download: IT
Download: CN
